High-precision spindle with a strict heat treatment process to improve the spindle strength wearresistance and service life
Built-inmultiple balancing methods for different rim structures
Threekinds ofpositioningoptions
Built-infault diagnosis andself-calibration function
Unitconversionprogramg-ounce,millimeter-inch
Can work continuously, batch testing tires, suitable for rim manufacturers
TECHNICAL PARAMETERS
| Voltage | 110/220/380V |
| Rim diameter | 12-24" |
| Mix wheel diameter | 980mm |
| Mix wheel width | 4-15" |
| Power | 0.25/0.37kw |
| Rim center diameter | ≤145/165mm |
| Balance cycle | 7s |
| Speed | 180rpm |
| Precision | ±1g |
| Packing | 1150*830*1200mm |
| Net/Gross weight | 145kg/171kg |
