High-precision spindle with a strict heat treatment process to improve the spindle strength
wearresistanceand service life
Built-in multiple balancingmethods for different rim structures.
Three kinds of positioning options
Built-in fault diagnosis and self-calibration function
Unit conversion program, g-ounce,millimeter-inch
Can work continuously, batch testing tires,suitable for rim manufacturers
TECHNICAL PARAMETERS
| Power | 0.25kw |
| Rim center diameter | ≤145mm |
| Balance cycle | 7s |
| Speed | 180rpm |
| Precision | ±1g |
| Packing | 1050*700*1150mm |
| Net/Gross weight | 118/146kg |
| Voltage | 110/220V |
| Rim diameter | 12/24" |
| Mix wheel diameter | 650mm |
| Mix wheel width | 1.5-12" |
